The installation and commissioning of the ice-cream vending machine

Installation and commissioning of automatic cotton candy machine

The smart gravity cabinet does not need to be installed. After the machinery and equipment are in hand, fill the shelf with the complete goods and you can use it directly!

Replenish the smart gravity cabinet in time and place the goods. If there is vegetable food, clean the cabinet in time and check whether the equipment can operate normally.

※Do not switch the machine frequently to prevent damage to the machine and whether the camera angle is appropriate to see all directions.

1) It is strictly forbidden to directly unplug the power to shut down at any time. You should follow the shutdown steps to enter the touch screen and click the shutdown operation. Wait until the temperature drops below 60 degrees Celsius before shutting down, otherwise there will be a risk of coil burnout.
2) The marshmallow cannot be sugared during the production process. In addition, when adding sugar, the sugar in the sugar box should not be too full, otherwise it will cause sugar jam. After adding sugar, click the touch screen to enter the background to view the material, and click according to the color of the added sugar The corresponding material is added to confirm,
3) Click the start button on the touch screen, and the furnace head will rotate. Therefore, make sure that the water basin is installed before starting the machine, and all doors must be closed.
4) The bucket for cleaning the furnace head and the bucket for collecting waste water should be connected to the corresponding pipelines, and cannot be interchanged.
5) When doing internal cleaning, it must be shut down according to the standard process and the machine can be cleaned after disconnecting the power supply.
6) When moving the machine, move it steadily and avoid bumps. Long-distance transportation requires internal parts to be fixed and transported
7) When the machine has an alarm, follow the procedure to restore and eliminate it.

8) Clean the machine and the drip tray before leaving get off work every time,
9) Clean the water in the waste water bucket and the clean water bucket in the machine, and clean the filter
10) Moisten the rag to clean the profiling knife

The daily cleaning of the stove head of the classic version of the fully automatic cotton candy machine, the replenishment of materials (adding water, sticks and sugar), and the daily cleaning and switching of the machine inside. The cleaning tools are equipped with.

※When cleaning and maintaining, cut off the power of the machine, pay attention to the temperature of the stove head of the machine to avoid scalding, and do not start frequently to prevent damage to the machine.

The fins of the condenser of the ice cream vending machine freezer should be cleaned with a brush every one month or so to improve the heat dissipation effect. Use neutral soap or special detergent for cleaning.

※It should be noted that the power supply of the freezer should not be forcibly cut off. If the power supply is forcibly cut off, the power supply is turned on immediately when the refrigerant has a high pressure. The high pressure causes the motor to be overloaded. At this time, the starting current is about 20-30 times the normal value. . It is easy to burn the compressor. When the freezer is stopped, the temperature in the freezer should drop to a certain temperature value. The power can be cut off only after the thermostat automatically cuts off the power, so the compressor of the freezer cannot be started frequently.

1. No cooling at all

Answer: Check whether the power plug is off? The circuit breaker and fuse are broken? Is there a power outage or a part of the line has tripped?

Plug it back in. Open the refrigerator door and see if the light is on.

2. Abnormal noise

Answer: Check whether the refrigerator is placed steadily? Does the refrigerator touch the wall?

Adjust the adjustment feet of the refrigerator. Leave the wall.

3. Poor cooling effect

Answer: Check if there is too much stored food or hot food? Frequent opening and closing of doors or food bags caught in the door seal? Direct sunlight or close to the stove or stove? Poor ventilation? Is the temperature set to a high gear?

Put the hot food in after it has cooled down. Check and close the door. Move the refrigerator away from the heat source. Leave a distance and maintain good ventilation. Set to a suitable temperature.

4. The food in the refrigerator is frozen

Answer: Check whether the temperature setting of the refrigerator compartment is too low? Is the frozen food close to the inner wall?

Reset the temperature of the refrigerator compartment. Leave the frozen food out of the inner wall of the refrigerator.

5. There is a peculiar smell in the refrigerator

Answer: Check for spoiled food? Does the refrigerator need to be cleaned? Is there any packaging for heavy-tasting foods?

Throw away spoiled food. Clean the refrigerator. Pack the heavy-tasting food.

1. There is no response when booting up

Answer: Check whether the input power is normal. Check whether the power switch is turned on.

2. The lights are not bright

Answer: Check whether the power supply and connectors are normal. Check whether the light bar is damaged.

3. Cannot scan QR code to pay

Answer: Check whether the payment box is bound to the connection. BCheck the power supply of the box.

4. No sound

Answer: Check whether the set volume is turned off and on. Check whether the motherboard and speaker cables are normal.

5. The advertising player does not play

Answer: A. Check whether the memory card is connected properly. B. Check whether there is a file or the format in the memory card is normal.

1. There is no response when booting up

Answer: Check whether the input power is normal. Check whether the power switch is turned on.

2. The lights are not bright

Answer: Check whether the power supply and connectors are normal. Check whether the light bar is damaged.

3. Cannot scan QR code to pay

Answer: Check whether the payment box is bound to the connection. BCheck the power supply of the box.

4. No sound

Answer: Check whether the set volume is turned off and on. Check whether the motherboard and speaker cables are normal.

5. The advertising player does not play

Answer: A. Check whether the memory card is connected properly. B. Check whether there is a file or the format in the memory card is normal.

1. There is no response when booting up

Answer: Check whether the input power is normal. Check whether the power switch is turned on.

2. The coin acceptor does not work

Answer: Check whether the coin acceptor circuit is in good contact. Check that the coin acceptor is normal.

Answer: Check whether the control board is normal.

3. The lights are not bright

Answer: Check whether the power supply and connectors are normal. Check whether the light bar is damaged.

4. Gifts are not counted

Answer: Check whether the power supply and photoeye are normal. Check whether the stopwatch is damaged.

5. Scan QR code to pay

Check whether the payment box is bound to the connection. BCheck the power supply of the box.

6. The crane can’t move left and right or back and forth

Answer: Check whether the joystick cable and joystick are normal. B. Check whether the motor of the crane is normal.

Answer: Check the circuit of the crane connected to the main board.

7. The machine temperature exceeds the limit alarm

Answer: Check whether the settings are normal. Check if the refrigerator is working properly.

8. No sound

Answer: Check whether the set volume is turned off and on. Check whether the motherboard and speaker cables are normal.

9. The start button does not respond

Check whether the keys are normal. Check the wiring from the motherboard to the button.

10. The crown block cannot be reset

Answer: Check whether the settings are normal. Turn off the power and restart the machine.

11. Crane paws cannot be closed or normally closed

Answer: Check whether the crane motor is short-circuited. Check whether the voltage setting of the paw is normal.

Answer: Check the connected circuit and motherboard.

12. The advertising player does not play

Answer: A. Check whether the memory card is connected properly. B. Check whether there is a file or the format in the memory card is normal.
